MEAN WELL RID-125-2405 Switching Power Supplies O/P +24V4.6A +5V3A

Width: 98.04 mm (3.86 in)

Height: 38.1 mm (1.5 in)

Length: 198.88 mm (7.83 in)

Efficiency: 83 %

Unit Weight: 700 g

Output Power: 125.4 W

Input Voltage: 88 VAC to 132 VAC, 176 VAC to 264 VAC, 248 VDC to 373 VDC

Mounting Style: Chassis

Isolation Voltage: 3 kVAC

Number of Outputs: 2 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 4.6 A

Output Voltage-Channel 1: 24 VDC

Output Voltage-Channel 2: 5 VDC

Operating Temperature Range: - 25 C to + 70 C

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 25 C
