Width: 25.4 mm (1 in)
Height: 10.2 mm (0.402 in)
Length: 50.8 mm (2 in)
Industry: Industrial
Dimensions: 50.8 mm x 25.4 mm x 10.2 mm
Adjust Type: Fixed
Application: Bus, Railway, Telecom/Datacom System
Unit Weight: 28.500 g
Output Power: 20 W
Input Voltage: 8.5 VDC to 160 VDC
Mounting Style: Through Hole
Isolation Voltage: 3 kV
Number of Outputs: 2 Output
Input Voltage - Max: 160 V
Input Voltage - Min: 8.5 V
Input Voltage, Nominal: 110 V
Output Current-Channel 1: 417 mA
Output Current-Channel 2: 417 mA
Output Voltage-Channel 1: 24 V
Output Voltage-Channel 2: - 24 V
Maximum Operating Temperature: + 95 C
Minimum Operating Temperature: - 40 C
