Width: 7.1 mm (0.28 in)
Height: 11.5 mm (0.453 in)
Length: 19.7 mm (0.776 in)
Industry: Medical
Dimensions: 19.7 mm x 7.1 mm x 11.5 mm
Application: Medical Devices, Wireless Network
Unit Weight: 2.800 g
Output Power: 2 W
Input Voltage: 4.5 VDC to 5.5 VDC
Mounting Style: Through Hole
Isolation Voltage: 6 kV
Number of Outputs: 2 Output
Input Voltage - Max: 5.5 V
Input Voltage - Min: 4.5 V
Input Voltage, Nominal: 5 V
Output Current-Channel 1: 67 mA
Output Current-Channel 2: 67 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 95 C
Minimum Operating Temperature: - 40 C
