Gain: - 0.8 dBi, 3.6 dBi, 4.1 dBi
VSWR: 2.9:1, 1.4:1, 1.4:1
Length: 69 mm
Bandwidth: 900 MHz, 2100 MHz, 2600 MHz,
IP Rating: IP67, IP69, IK09
Impedance: 50 Ohms
Polarization: Linear
Power Rating: 25 W
Mounting Style: Screw Mount
Number of Bands: 6 Band
Center Frequency: 698 MHz to 960 MHz, 1710 MHz to 2170 MHz, 2500 MHz to 2700 MHz, 698 MHz to960 MHz, 1710 MHz to 2170 MHz, 2500 MHz to 2700 MHz
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: SMA-Male
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
