MATRIX PEL-9800S24096 Programmable DC Electronic Load (2400W/ 24000W, 0-80V/ 0-800V, 0-96A/ 0-960A)

Power: 2400W/ 24000W

Voltage Range: 0-80V/ 0-800V

Current Range: 0-96A/ 0-960A

CC Mode

Range: 0-96A/ 0-960A

Accuracy: 0.05%+0.1%FS/ 0.1%+0.1%FS

CR Mode

Range: 0.02Ω ~ 210Ω/ 0.875Ω~1.7ΚΩ

Accuracy: Vin/Rset*(0.2%)+0.2%IF.S

CV Mode

Range: 0-80V/ 0-800V

Accuracy: 0.05%+0.05%FS

CP Mode

Range: 0-2400W/ 0-24000W

Accuracy: 0.2%+0.2%FS

Dynamic Mode

T1&T2: 0.025-10mS/ 1mS-30S

Slew Rate: 16mA-3.2A/uS/ 0.16A-32A/uS

Accuracy: 10%±20uS

Measure Function

Voltage Range: 0-80V/ 0-800V

Accuracy: 0.025%+0.05%FS

Current Range: 0-96A/ 0-960A

Accuracy: 0.05%+0.1%FS

Power Range: 0-2400W/ 0-24000W

Accuracy: 0.2%+0.2%FS

General Parameter

Short Current: 960A

Size (W*H*D) mm: 550 X 1520 X 720

Weight (Kg): 316
