MATRIX MPS-3063S Multi-channel DC Power Supply (31V, 6A)

Rated output:

Voltage: 0 ~ 31V * 2/0 ~ 6V * 1

Electric current: 0 ~ 6A * 2/0 ~ 3A * 1

Load regulation:

Voltage: ≤0.01%+ 3mV

Electric current: ≤0.01%+ 3mA

Power regulation:

Voltage: ≤0.01%+ 3mV

Electric current: ≤0.01%+ 3mA

Set resolution:

Voltage: 10mV

Electric current: 1mA

Readback resolution:

Voltage: 10mV

Electric current: 1mA

Set accuracy:

Voltage: ≤0.03%+ 2 bytes

Electric current: ≤0.1%+ 8mA

Readback accuracy:

Voltage: ≤0.03%+ 2 bytes

Electric current: ≤0.1%+ 8mA

Ripple and noise:

Voltage rms: ≤2mVrms

Electric current: ≤5mArms

Series and parallel setpoint accuracy:

Voltage: ≤0.02%+ 2 bytes

Electric current: ≤0.1%+ 30mA

Memory:

Store / Call: 40 groups

Features: Timing off output

Timer: time setting: 0.1s ~ 99999.9s

Resolution: 0.1s

Operating temperature: 0 ~ 40 ° C

Bare metal size: mm: 255 * 110 * 380

Packing size: mm: 325 * 210 * 475

Net weight: kg: 8.5

Gross weight: kg: 10
