Manncorp HB-350W-ST Vertical LIFO/FIFO Buffer

Manufacturer: Manncorp - USA

Model: HB-350W-ST

Origin: China

Warranty: 12 months

PCB Size: 50 mm L x 50 mm W to 400 mm L x 350 mm W (1.97" L x 1.97" W to 15.75" L x 13.78" W)

PCB Thickness: 0.6 mm min. (0.024" min.); 2.5 mm max. (0.098" max.)

Air Supply Pressure: 5-6 Kg/cm2 (70-85 psi)

Air Consumption: 15 l/min (.53 CFM)

Voltage: 110 VAC, 50/60 Hz

Power:200 VA max.

Machine Dimensions: 600 mm L x 1000 mm W x 1600 mm H (23.5" L x 39.5" W x 63" H)

Net Weight: 200 Kg (441 lbs.)

Shipping Weight: 260 Kg (574 lbs.)
