Manncorp BL-460W-ST Magazine PCB Loader

Manufacturer: Manncorp - USA

Model: BL-460W-ST

Origin: China

Warranty: 12 months

PCB Size: 120 x 120 mm to 535 x 460 mm (4.72" x 4.72" to 21.06" x 18.11")

Magazine Size:535 mm L x 530 mm W x 570 mm H (21.06" L x 20.87" W x 22.44" H)

Selectable Pitch:10, 20, 30, or 40 mm

Conveyor Direction:Left to right (standard) or right to left (optional) operation

PCB Thickness:0.4 mm min. (0.016" min.)

Air Supply Pressure:5-6 Kg/cm2 (70-85 psi)

Air Consumption:10 l/min (.35 CFM)

Voltage: 110 VAC

Power:300 VA max.

Machine Dimensions:1750 mm L x 960 mm W x 1150 mm H (69" L x 38" W x 45" H)

Net Weight:300 Kg (660 lbs.)

Shipping Weight: 340 Kg (750 lbs.)
