Operating and display unit: Tablet PC with M2 software
Measuring range X/Y (mm): 200 / 100
Z travel path (mm): 200
Maximum table load (kg):20
Measuring system: Built-in incremental scale
Measuring system - resolution (mm): 0.001
Measuring system - E1 X/Y (µm): 1.9 + (L/100) L in mm
Measuring system - E2 XY (µm): 2.9 + (L/100) L in mm
Magnification: 8– 40x variable zoom
Image field - diameter (mm): 23 – 4
Max. height of test piece (mm): 185
Max. height of test piece / 0.5-fold (mm): 110
200 extension in Z (mm): 385
200 extension in Z / 0.5-fold (mm): 310
Illumination: LED Incident and transmitted light, individually adjustable
Energy supply: 230 V / 50 Hz
H x W x D (mm): 550 x 650 x 530
Optional:
