Parameters: Ra, Ry, Rmax, Rz
Stylus: 5 µm / .0002”
Data interface: RS232C, USB
Rechargeable batteries: Battery, 9V
H x W x D (mm): 140 x 76 x 6.35
Weight (kg): 1.03
Measuring principle: Skid probe system
Probe: Piezoelectric skid probe
Measuring range (mm): Ra–6.35µm/250Ry,Rmax,Rz–25.3µm/999µin
Profile resolution: 0.01 µm / 1 µin
Number n of sampling length according to ISO/JIS: Selected: 1–5
Measuring force (N): 15 mN
