MACOM MRF171A RF Power MOSFET 100-200MHz 45Watts 28Volt Gain 17dB

Gain: 17 dB

Technology: Si

Unit Weight: 8.760 g

Output Power: 45 W

Configuration: Single

Mounting Style: SMD/SMT

Operating Frequency: 150 MHz

Transistor Polarity: N-Channel

Pd - Power Dissipation: 115 W

Vgs - Gate-Source Voltage: + 20 V

Id - Continuous Drain Current: 4.5 A

Maximum Operating Temperature: + 150 C

Minimum Operating Temperature: - 65 C

Vds - Drain-Source Breakdown Voltage: 65 V

Vgs th - Gate-Source Threshold Voltage: 2.5 V
