Impedance: 50 Ohms
Tolerance: 0.5 dB
Technology: GaAs
Attenuation: 31 dB
Maximum VSWR: 2.2
Power Rating: 34 dBm
Insertion Loss: 3.8 dB
Mounting Style: SMD/SMT
Number of Bits: 5 bit
Maximum Frequency: 3 GHz
Minimum Frequency: DC
Number of Channels: 1 Channel
Attenuator Step Size: 1 dB
Operating Supply Voltage: 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
