AC / DC Voltage (UAC / DC):
400 mV / 0.1 mV (DC only); 4 V / 0.001 V; 40 V / 0.01 V; 400 V / 0.1 V; 1000 V / 1 V
AC / DC Current (IAC / DC – direct):
400 µA / 0.1 µA; 4000 µA / 1 µA; 40 mA / 0.01 mA; 400 mA / 0.1 mA
AC / DC Current (IAC / DC – clamp):
400 A / 0.1 A; 2000 A / 1 A
Resistance (R):
400 Ω / 0.1 Ω; 4 kΩ / 1 Ω; 40 kΩ / 10 Ω; 400 kΩ / 0.1 kΩ;
4 MΩ / 1 kΩ; 40 MΩ / 10 kΩ
Frequency (F):
5 Hz / 0.001 Hz; 50 Hz / 0.01 Hz; 500 Hz / 0.1 Hz;
5 kHz / 1 Hz; 50 kHz / 10 Hz; 100 kHz / 100 Hz
Capacitance (C):
50 nF / 10 pF; 500 nF / 100 pF; 5 µF / 0.001 µF; 50 µF / 0.01 µF
Other Parameters:
RS232 / USB PC interface
Power supply: 9 V battery
Dimensions: 73 × 255 × 38 mm
