Compatible Detectors: GM, scintillation, or proportional
Display: 3-digit auto-ranging LCD with large 20 mm (0.8 in.) digits.
Units: (k)cps, (k)cpm, (k)Bq, (k)dpm, (μ)(m)R(/h), (μ)(m)Sv(/h).
Indicators: bar graph, MAX, ALARM, USB, audio, low battery.
Display Range:
0.0 cps to 99.9 kcps
0.00 cpm to 999 kcpm
0.00 Bq to 99.9 kBq
0.00 dpm to 999 kdpm
0.00 μR/h to 999 R/h
0.00 μSv/h to 999 Sv/h
Operational display ranges are dependent on the detector and dead time configuration. The minimum and maximum display can be set to limit the display to the calibrated range.
Linearity: within 10% of true value
Data Logging: Can store up to 1000 data points internally. Requires Lumic Data Logger Kit, see Options.
Response Time: User-selectable from 1 to 60 s, or Auto-Response Rate FAST or SLOW
Alarms: Two adjustable count rate, exposure/dose, and scaler alarm setpoints adjustable over the display range
Overload Protection: High count rate saturation protection prevents false display of lower count rates. "OL" will appear on the display and an audio warning will be triggered.
High Voltage: 400 to 1500 Vdc
Threshold: -2 to -100 mVdc
Audio: Approximately 4.5 kHz, click audio greater than 65 dB at 0.6 m (2 ft), alarm audio greater than 72 dB
Power: Four alkaline “AA” batteries
Temperature Range: -20 to 50 °C (-5 to 122 °F)
May be certified for operation from -40 to 65 °C (-40 to 150 °F)
Enviornmental Rating: NEMA rating of 5 or IP rating of 53
Size (H x L x W): 16.5 x 11.4 x 21.6 cm (6.5 x 4.5 x 8.5 in.)
Weight: 0.7 kg (1.6 lb) (excluding detectors and clips)
