Frequency sweep range (Hz): 5 ~ 400
The maximum acceleration (m/s2): 170
The maximum load test (kg): 100
Maximum no-load displacement (MMP – p): 0 ~ 5
Vibration waveform: sine wave
The axial vibration: vertical + level
Vibration mode: electromagnetic vibration
Cooling: air cooling
Working temperature (℃): 0 ~ + 40
Working humidity (RH %): 0-90, no condensation
Single-phase AC power supply requirements: 220 v / 50 hz plus or minus 10%
System consumed power (KVA): 2.2
Countertop materials: magnesium alloy
Mesa screw size (standard): M8 (customizable)
Mesa screw number: 8 (customizable)
Taiwan’s total weight (kg): 150
Working mesa dimension W.D.H (mm): 450 * 450 * 43
W.D.H body size (mm): 1300 * 570 * 570
vibration testing machine technical parameters
Product overview: electromagnetic vibration test series are widely used and defense, aerospace, communication, electronics, automobile, household electrical appliances and other industries.Early failure, this type of equipment is used for assessment of simulating actual working condition and structure strength test, the product application scope is broad and wide applicable, test effect is remarkable, and reliable.
Does human operation and control, the use of professional measurement and control software, make the equipment working more stable, more reliable
When the whole machine adopts complex industrial material manufacturing, precision machining, silent
Panel using magnesium aluminum alloy materials, you can be completely isolated magnetic field interference, effectively prevent the analyte magnetization
When frequency sweep and constant frequency operation mode, to adapt to the testing requirements of different industries
When high frequency output, synchronous excitation at four o ‘clock, mesa vibration evenly
Magnetic resistance and strong anti-jamming capability
Have a safe and reliable protection
When the machine body adopts high efficiency low noise fan cooling, ensure that run continuously for a long time
