Resolution: 1/150 000
Range of speed: 50～500mm/min
Motor: AC motor
Capacity choice: 0-2000KG,Load cell Option (500KG, 1000KG, 2000KG)
Stroke: 1200mm(excluding clamp)
Sensor sensitivity: 1–40mV/V
Effective measuring range: 0.5～100%F.S；
Effective testing space: 600mm MAX
Accuracy: ±0.5%
Operation method: Windows operation
Accessories: tensile grips, system operation manual
Weight: 230kg
Dimention: 96×65×230cm(W×D×H)
Power: 1PH, AC220V, 50/60Hz
Force protection: system setting
Emergency stop device: Upper and lower limit safety setting, emergency stop key, program strength and elongation setting, test piece damage sensing
Computer connector: RS232,Provide USB Convertor
Computer system: Support Windows XP,Win 7 and Win 10,QC Tech software, At the same time, the power, elongation and test graphics (resolution 1024 x 768) are available, which can be selected by various test modes, such as tensile, compression, bending, Peel and Shear test.
Unit Choose: kgf, lbf, N, KN, KPa, Mp
