Operating Frequency: 0.5MHz～15MHz
Scanning Range: 0-6000mm
Vertical linearity error: ≤4%
Horizontal linearity error: ≤0.1%
Dynamic Range: ≥32dB
Noise Level: ＜8%
Velocity Range: 1000～9999（m/s）
Testing Sensitivity: ≥60dB (Depth 200mm, Φ2 flat bottom hole)
Gain Range: 0~110dB
Standard Probes:
Straight probe: 2.5MHz, diameter 20mm, cable Q9-Q9
Angle probe: 4MHz, 60 degree, 8*9 mm, cable Q9-C5
Standby Time: ≥ 10 hours of continuous work
Temperature: (- 20 ~ 70) ℃
Humidity: (20 ~ 95)% RH
Overall dimension: 240×160×40mm
Weight: 1.2kg
Standard Delivery: Main Unit, Straight probe, Angle probe, Power adapter, BNC cables, PC software, Manual,Certificate, Warranty card
Optional Accessories: Optional probes, Cables, Calibration blocks, Coupling agent
