Pressure capacity: 50T
Pressure gauge: The two-node pressure is adjustable, and the precision of pressure adjustment is 10%
Plate size (mm metric): Plate size (mm metric) 250*250/300*300/350*350/400*400/450*450/500*500/600*600 [mm]
Hot press plate material: High temperature resistant imported steel plate, surface carbonization quenching, special treatment of fast heat conduction, parallel pressure does
not change, wear-resistant.
Platen hardness: 50〜60HRC
Flatness of the platen: <0. 03mm
Flatness of platen: <0.16mm
Temperature range: from normal temperature to 250°C [Maximum temperature can be customized 500 degrees] [Select one of the price lists shall prevail]
Temperature uniformity: The larger the platen, the higher the Temperature uniformity, the worse the temperature uniformity.
Temperature control unit: Precision module, with PLC touch screen control, touch screen internal display, numerical display.
Temperature control mode self-setting with high precision sensor, Temperature control accuracy: ±1.0°C.
Timer: Displays the Settings on the touch screen. The time range is 0.1S ~ 99min ~ 9.9hr
Heater: [According to the pressure plate area configuration of different power packing pressure plate temperature uniformity, not the same power]
Warming time: The takes about 15 minutes from the normal temperature to 160 °C
Two hot plates: can be set to control the temperature
Method of heating: electric heating
Two pieces of cold: plate Water cooling laminates are controlled by water temperature
Mode of cooling: Tap water cooling/chiller cooling [Optional price list shall prevail]
Oil pressure system:
The Oil pressure system adopts CREE.6 hydraulic flow closed loop control system. The oil pump drives high-performance electro-hydraulic with the piston of the high precision non-resistance cylinder to implement the constant rate control mode, with the automatic pressure compensation function.
A pressure automatic pressure, strong load force, stable lifting; Automatic pressure, pressure retention, pressure relief.
Cylinder stroke: Cylinder stroke Max 150mm [customizable] [Select one subject to the quotation]
Cylinder speed: 11mm/s
Pressure gauge: 0 〜200kg/sq.cm
Die opening mode: Automatic ascent and descent (with manual and automatic dual functions)
Safety device: Safety shield, safety door.
Number of safety devices: four
Supporting mold frame [Optional]: custom
Main engine volume: (WXDXH)1200x750x1650 mm
Supply voltage: 3-phase electricity, AC380V
Machine weight: 780kg
