Capacity, l/h
distillate: 13.8
double distillate:12.0
Electrical conductivity of product water
double distillate: 1.0-1.2 μS/cm
distillate: 5.0 μS/cm max
Quality of product water: Type II, III
Product water temperature, °С
distillate: from 70 to 85
double distillate: 40 max
Current type, frequency, voltage: three-phase AC, 50 Hz, 380 V
Power consumption:
distillate: 8.1 kVA
double distillate: 15.3 kVA
Source water consumption, l/h (at water t from 10 to 12 °С at pressure from 0.2 to 0.4 MPa)
distillate: 104.0
double distillate: 240.0
Source water pressure, MPa: 0.1 – 0.4
Dimensions (LxWxH), mm: 675×365×470
Type of mounting: Desktop mounting with adjustable legs. Wall mounting is possible.
Weight with control unit, kg: 30.0
Heating elements: the first distillation step: Tubular heating element 2.0 kW 220V (stainless steel) - 3 pc. the second distillation step: Tubular heating element 1.8 kW 220V (stainless steel) - 3 pc.
Factor of water purification from radionuclides, min: 4000
