Width: 6.5 mm
Height: 3.5 mm
Length: 7.3 mm
Fall Time: 10 us
Rise Time: 10 us
Output Type: NPN Phototransistor
Unit Weight: 400 mg
Mounting Style: Through Hole
Isolation Voltage: 5000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 60 mA
Vf - Forward Voltage: 1.65 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 160 %
Pd - Power Dissipation: 250 mW
Maximum Collector Current: 150 mA
Current Transfer Ratio - Max: 320 %
Current Transfer Ratio - Min: 160 %
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 55 C
Maximum Collector Emitter Voltage: 70 V
Maximum Collector Emitter Saturation Voltage: 300 mV
