Gain: 6.1 dBi, 6.1 dBi, 6.9 dBi
VSWR: 1.2, 3.3, 2.6
Style: I-Bar Flex
Width: 20 mm
Height: 49 mm
Length: 110 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Wavelength: 1/2 Wave
Application: Wireless Applications, U-NII, ISM Applications, IoT Devices, Smart Home Networking, Sensing, Remote Monitoring
Unit Weight: 1.500 g
Cable Length: 100 mm
For Use With: WiFi 6, WiFi 6E, 802.11ax, WiFi, WiFi 4, WiFi 5, 802.11, 802.15.4, Bluetooth
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: Embedded Dipole
Number of Bands: 3 Band
Center Frequency: 2.4 GHz, 5 GHz, 6 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 7.125 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: MHF / U.FL
Protocol - WiFi - 802.11: 802.11 b/g/n/ac/ax, WiFi 4, WiFi 5, WiFi 6, WiFi 6E
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/4G/5G, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
