Gain: 3.4 dBi, 4.8 dBi, 5 dBi, 3.9 dBi, 3.4dBi, 4.1 dBi, 4.6 dBi
VSWR: 3.3, 2.2, 2.6, 3.2, 2.3, 1.9, 2.2
Style: Tilt/Swivel
Width: 29 mm
Length: 78.7 mm
Diameter: 10 mm
Impedance: 50 Ohms
Technology: Cellular
Wavelength: 1/4 Wave
Application: Worldwide Cellular, Low Power Wide Area, ISM Applications, FirstNet Public Safety, IoT Devices, Gateways
Unit Weight: 10.512 g
Polarization: Linear
Power Rating: 10 W
REACH - SVHC: Details
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 7 Band
Center Frequency: 650 MHz, 800 MHz, 850 MHz, 900 MHz, 1700 MHz, 1800 MHz, 2400 MHz, 2700 MHz, 3300 MHz, 3800 MHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 3.8 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Antenna Connector Type: SMA Plug
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 4G/5G, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
