Gain: 3.7 dBi, 3.3 dBi, 2.2 dBi, 3.3 dBi, 5 dBi, 5.7 dBi
VSWR: 4.8, 1.7, 4.9, 3.5, 3.1, 2
Style: I-Bar Flex
Width: 17 mm
Height: 0.2 mm
Length: 64 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Wavelength: 1/2 Wave
Application: Worldwide Cellular, Low Power Wide Area, ISM Applications, Global Navigation
Unit Weight: 7.326 g
Cable Length: 100 mm
For Use With: LTE, GSM, UMTS, 2G/3G/4G, CBRS, GPS, GNSS, GLONASS, Beidou, COMPASS, GALILEO
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: Embedded Dipole
Number of Bands: 6 Band
Center Frequency: 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1.575 GHz, 1.7 GHz, 1.8 GHz, 1.9 GHz, 2.1 GHz, 2.3 GHz, 2.4 GHz, 2.5 GHz, 3.3 GHz, 3.4 GHz, 3.5 GHz, 3.6 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 3.8 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: MHF1 / U.FL
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GPS
Protocol - WiFi - 802.11: WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS, CBRS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
