Frequency: 20kHz / 15kHz
Power: 20kHz: 2000W / 2600W / 3200W; 15kHz: 2600W / 3200W / 3200W (Landing type supports)
Input Voltage: AC220V
Cylinder Size (mm): 63×75 / 50×75 / 80×75
Machine Journey: 470mm
Output Time: 0.01-9.99s
Air Pressure: >1, ≤7bar
Welding Capability: Φ170mm / Φ220mm / Φ300mm
Operation Switch: Two-hand release, emergency stop button at the front, and adding external control switch supported.
Dimension (Press): 680 × 400 × 1508 mm (Standard) / 735 × 650 × 2158 mm (Landing Type)
Dimension (Analog Generator): 530 × 405 × 155 mm
Net Weight (Press): 74.5kg (Standard) / 190kg (Landing Type)
Net Weight (Analog Generator): 14.5kg
Heightened Pillar (Optional): 150mm / 200mm / 300mm height options available.
