Frequency: 20kHz / 15kHz
Power: 20kHz: 2000W / 2600W; 15kHz: 2600W / 3000W
Input Voltage: AC220V
Cylinder Size (mm): 63 × 75 / 80 × 75
Machine Journey: 336mm
Output Time: 0.01-9.99s
Air Pressure: >1, ≤7bar
Welding Capability: 20kHz: Φ170mm / Φ220mm; 15kHz: Φ220mm / Φ260mm
Operation Switch: Two-hand release, emergency stop button at the front, and adding external control switch supported.
Dimension (Press): 680 × 400 × 1552 mm
Dimension (Digitalization Generator): 430 × 230 × 108 mm
Dimension (Analog Generator): 560 × 420 × 155 mm
Net Weight (Press): 84kg
Net Weight (Digitalization Generator): 6.5kg
Net Weight (Analog Generator): 17.54kg
