Internal Dimension: 1000*1000*1000 mm D*W*H
Overall Dimension: 2600*5400*4100 D*W*H
Interior Volume: 1000L
The load Turntable: 50kg
The diameter of Turntable: 800mm
Rain and Blowing Rain:
Final rain droplet velocity: 9m/s on test item
Rainfall rate: ≥ 1.7 mm/min
Droplet size: 0.5mm ~ 4.5mm
Test specimen heating range: Water temperature +10°C (max +55°C)
Test time: 0 ~ 999min. adjustable
Exaggerated:
Nozzle pressure: 276kpa
Rainfall rate: 20.8L/min
Nozzle amount: One nozzle for each 0.56m2 of surface area and position each about 48cm from in the test surface
Droplet size: 0.5mm ~ 4.5mm
Test time: 0 ~ 999min. adjustable
Drip:
Drip area dimensions: 1600*1000mm , height can be adjustable
Drip holes: 20 to 25.4mm
Distance between hole: 25mm
Volume of water: ≥280L/m2/h
Test specimen heating range: Water temperature +10°C (max +55°C)
Door Lock: Electromagnetic lock
Exterior Material: A3 Steel Plate with protective coating
Interior Material: SUS304 stainless steel
Standard: MIL-STD- 810H
Advantages
1. Extreme Weather Simulation: The chamber replicates heavy rain, wind-driven showers, and pressurized water sprays with adjustable rain rates (10–20 cm/hour) and wind speeds (5–18 m/s). This ensures products experience realistic storm conditions, helping engineers identify vulnerabilities before field deployment.
2. Full 360° Exposure: Equipped with a liftable drip tray and a 360-degree nozzle array, the chamber delivers uniform water coverage from all angles. Coupled with a rotating turntable (1–7 r/min), every surface of the test sample is consistently exposed for accurate and repeatable results.
3. Customizable Test Profiles: Programmable PID control allows precise adjustment of rain intensity, droplet size (0.5–4.5 mm), wind speed, and test duration. Users can create complex sequences to simulate multiple storm scenarios, increasing test flexibility and efficiency.
4. Durable and Corrosion-Resistant Construction: The interior is crafted from SUS304 stainless steel to withstand high-humidity exposure, while the A3 steel exterior with protective coating ensures long-term durability. This robust build supports repeated testing without degradation of chamber performance.
5. Safe and Reliable Operation: Integrated water-electricity separation, electromagnetic door lock, and over-pressure protections safeguard both the operator and the equipment. These features minimize risk during high-intensity water tests, ensuring safe and uninterrupted testing cycles.
