Internal Dimensions (mm): 1000*1000*1000 D*W*H
Overall Dimensions (mm): 1100*1460*1900 D*W*H
Interior Volume (L): 1000
Distance from Specimen to Nozzle: Approx.400mm
Rain Nozzle: 2 holes
Rain Nozzle Hole: Φ0.5mm
R1 Water Flow Rate: 1.9L/min.
R2 Water Flow Rate: 3.3L/min.
Spray Nozzle: 40 holes
Spray Nozzle Hole: Φ1.2mm
S1 Water Flow Rate: 24.5L/min
S2 Water Flow Rate: 39.2L/min
Water Pressure at Nozzle: 0.03 ~ 0.30MPA
Turntable Rotation Speed: 17r/min
Water Pressure Control: Flow meter
Controller: Programmable color LCD touch screen controller, Ethernet connection
Water supply system: Water tank, booster pump, Automatic water supply, Water purification system
Safety Device: Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection
Exterior Material: Steel Plate with protective coating
Interior Material: SUS304 stainless steel
Observation Window: Double layer insulating glass with wiper
Advantages
1. High-Fidelity Water Simulation: Equipped with 2 rainfall nozzles and 40 spray nozzles, the chamber can accurately replicate natural rain, wind-driven rain, and heavy spray conditions. Adjustable flow rates from 1.9 L/min to 39.2 L/min and pressures up to 0.30 MPa ensure testing closely mirrors real-world exposure, providing dependable waterproof performance data for automotive components and electronic devices.
2. 360° Rotational Coverage: The sturdy stainless-steel turntable rotates at 17 rpm, delivering uniform water exposure across all surfaces of the test specimens. This comprehensive coverage eliminates blind spots, helping engineers identify potential weak points and improve product durability.
3. Efficient Water Management: The closed-loop circulation and filtration system reduces water consumption while maintaining consistent test conditions. This eco-friendly design not only lowers operational costs but also ensures repeatable and stable performance during long testing cycles.
4. User-Friendly Intelligent Control: The touchscreen PID controller allows precise adjustment of water flow, pressure, test duration, and turntable rotation. Real-time monitoring and alerts via Ethernet simplify operation and enhance testing accuracy.
5. Durable and Safe Construction: Constructed with corrosion-resistant SUS304 stainless steel and featuring a large observation window with wiper, the chamber is built for prolonged water exposure and easy monitoring. Safety mechanisms, including over-pressure, low-water, and electrical leakage protections, ensure reliable and secure operation for both personnel and equipment.
