Internal Dimension (mm): 1000*2000*1000
Overall Dimension (mm): 1330*2450*1990
Useful Volume (L): 2000
Temperature Range: Ambient ~ +50℃
Humidity Range: < 30% RH
Normal Wire Diameter: 50um
Nominal Width of a Gap Between wires: 75um
Fight Time: 0 ~ 99H59M
Blowing Time: 0 ~ 99H59M
Specimen Power Outlet: Dust-proof socket 16A
Vacuum System: Equipped with a pressure gauge, air filter, pressure regulator, connecting tube
Controller: Programmable color LCD touch screen controller, Ethernet connection
Door Lock: Electromagnetic lock
Safety Device: Over-temperature Protection; Over-current Protection; Earth Leakage Protection;Phase Sequence Protection
Exterior Material: A3 Steel Plate with protective coating
Interior Material: SUS304 stainless steel
Observation Window: Interior lighting, double-layer thermo stability silicone rubber sealing
Standard Configuration: Sample shelf, dust wiper, talcum powder(5kgs)
Advantages
1. Accurate Dust Simulation: The chamber delivers a controlled dust concentration of 2–4 kg/m³ with a nominal particle size of 50 μm and a wire gap width of 75 μm, precisely reproducing real-world sand and dust intrusion scenarios.
2. Versatile Specimen Capacity: Available in 800 L and 1000 L models (internal dimensions 800×1000×1000 mm and 1000×1000×1000 mm), the chamber can accommodate both small electronic devices and larger industrial components, with a 16 A dust-proof power outlet for live testing.
3. Safe & Observant Operation: Features include a view window with wiper, built-in lighting, electromagnetic door lock, and integrated wiring port. The vertical dust circulation system maintains a nominal particle diameter of 50–55 μm, preventing caking and providing a stable, uniform test environment.
4. Durable & Safe Construction: Equipped with SUS304 stainless steel interior and an electromagnetic door lock, the chamber ensures long-term corrosion resistance and operator safety. The chamber’s maximum noise level is ≤65 dBA for a quiet work environment.
5. Advanced Programmable Control: The color LCD touchscreen controller supports Ethernet and PC Link connections, allowing full programming of test durations up to 99 h 59 min, remote monitoring, and precise control over dust circulation, vacuum system, and heating elements.
