Software system: LF-Toutch-OS software system
Syringe specification: 0.5μl-100μL
Channel number: 1
Max stroke Range: 70 mm
Stroke resolution: 0.1905 μm/step
linear velocity range: 0.6096 um/min to 91.44 um/min
Linear velocity regulating resolution: 0.6096 um/min
Linear travel accuracy: error <±0.35%（>30% of pump stroke）
Linear thrust, maximum rated: > 10n
Thrust adjustment: 1-100% arbitrary adjustable.
Syringe selection: built-in syringe manufacturers, choose syringe model; Or custom syringe, direct input syringe diameter
Flow correction: through the calibration procedure to obtain more accurate fluid volume
Display: 4.3 inch color LCD, 480×272 resolution, color 65K
With screen display and transfusion volume, quantity of liquid, flow rate, direction, syringe specification, etc.
Animation display for operating status
Operation mode: touch screen and physical buttons
Power-off memory: keep saved parameters
Other features: pause and stop, warning tone, parameters lock
Fast forward and retreat quickly
Indicator, state signal output: one for stop state, another one for direction state
Control signal input: control start/stop and direction
Communication interface: RS485, MODBUS
Power supply: 100-240V AC / 20W
Working temperature: 5~40°C (41~104°F)
Working environment relative humidity: < 80% RH
Controller dimension: 245x205x105 mm (9.6×8.1×4.1 inch)
Drive dimension: 173x24x52mm (6.8×0.96×2.04 inch)
Weight: 2.25kg (4.96lbs)
