Specifications
Flow range: 15-2700 mL/min
Speed range: 50-3000 rpm/min
Speed resolution: 1rpm/min，accuracy:0.5%
Time dispensing: 0.1-99.99 secpmds
Pause time: 0.1-999.9 seconds
Dispensing times: 0-999
Ajusting way: keypad and touch screen operation
Display mode: 65565 Color LCD
power supply: AC 90-264V 50Hz/60Hz
Consumption: <150W
work environment: Environment 0 -40℃ ,humidity <80%
dimension size: 342*198* 182mm
Drive weight: 5.5kg
IP standard: IP31
CT 3000F suitable pump head
| Pump head | Gear materal | Pressure (MPa) | Flow range (mL/min) | Liquid temperature℃ |
| MS204XD0PT00000 | PEEK | ≤1.4 | 15-900 | -45-120 |
| MS209XD0PT00000 | PEEK | ≤0.9 | 30-1800 | -45-120 |
| MS213XD0PT00000 | PEEK | ≤0.8 | 45-2700 | -45-120 |
