Working temperature range: -30 ... 120 °C
Ambient temperature range: 5 ... 40 °C
Temperature stability: 0.05 ± K
Heater power max.: 8 kW
Max. power consumption: 11 kW
Current consumption: 16 A
Max. discharge pressure: 3.5 bar (50 Hz), 4.6 bar (60 Hz)
Max. pump flow pressure: 40 L/min (50 Hz); 65 L/min (60 Hz)
In / Outlet connection thread (outside): G 3/4"
Min. filling volume: 7.2 L
Max. filling volume: 20.5 L
Water cooling connection thread (inside): 3/4 ″
Recommended cooling water temperature: 15 °C
Cooling water flow rate: 14.5 L/min
Pressure difference cooling water min.: 0.8 bar
Maximal pressure cooling water: 10 bar
Dimensions (WxDxH): 560 x 550 x 1325 mm
Weight: 150 kg
Noise level: 62 dB(A)
Power supply: 400 V; 3/PE; 50 Hz & 460 V; 3/PE; 60 Hz
