Load
Rated capacity
N 25000
kN 25
kgf 2549
lbf 5500
Force accuracy : +/- 0.5% of reading, EN ISO 7500-1:2015 Class 0.5 ASTM E4
Resolution: 1:50,000
Data acquisition rate (max): 1000 Hz
Platen configuration: Fixed or floating
Dimensions
Distance between columns: 31” (800 mm)
Height : 77.5” (967 mm)
Width : 44” (1108 mm)
Depth : 37” (930 mm) Machine only
Vertical daylight: 48” (1440 mm)
Weight (instrument only) : Approx 400 kg (880 lbs)
Speed
Range
mm/min: 0.01 - 1000
in/min : 0.0004 - 39.4
Resolution mm/min : 0.001
Accuracy: Better than ±2% of indicated speed or ±20 microns/minute, whichever is greater
Displacement
Crosshead travel: 48” (1220 mm)
Resolution : 0.001 mm (1 micron)
Accuracy: ±0.1% of indicated position or ±0.01mm (10 microns), whichever is greater
Electrical supply
Voltage : 230V AC 50 Hz or 110V AC 60 Hz
Max power : 750W
Environment specification
Operating temperature : 10°C - 40°C
Operating relative humidity: 30-80% non-condensing
