Frequency Range: 1 – 300 Hz.
Maximum Stroke Options (Peak-To-Peak) : 2.5 In. (6.4 Cm); 4.0 In. (10.2 Cm); 6.0 In. (15.2 Cm)
Actuator Stall Force (At 3000 Psi (207 Bar)): 12,370 Lbs. (55 Kn)
Actuator Dynamic Force (At 3000 Psi (207 Bar)) : 8247 Lbs. (36.7 Kn)
Table Sizes : 48 In. (122 Cm) Square; 60 In. (152 Cm) Square; 72 In. (183 Cm) Square; 60 X 98 In. (152 X 249 Cm)
Standard Hole Patterns : 6 In. Grid, 3/8-16 Stainless Steel Inserts; 15 Cm Grid, M10 X 1.5 Stainless Steel Inserts
Power Requirements
System: 200 – 460 Vac; 50, 60 Hz; Three Phase
Controls: 100 – 240 Vac; 50, 60 Hz; Single Phase
Facility Requirements
Cooling Water : Standard Hps – 6 Gpm At 60⁰F (23 L/Min. At 15.5⁰C)
Plant Air: 80 Psi (552 Kpa), 1 Scfm
For 1-G Supports (Optional)
