Reaction cell positions: 10
Reaction cell diameter: 24 mm
Reaction cell power: 100 W
Working temperature range: -20°C to +150°C
Temperature accuracy: ±0.1°C
Temperature stability: ±0.1°C
Temperature ramping: Independent for each cell
Maximum heating rate: +48°C/min
Maximum cooling rate: -36°C/min
Temperature variation with time function: Yes
Heating and cooling mode: Peltier module system
Stirring rate: 100 to 1,500 RPM
Sample volume for each cell: Up to 30 mL
Sampling during the reaction: Yes
Inert gas atmosphere: Yes
Separate electronic module: Yes
Built-in anti-condensing circuit: Yes
Overheating protection: Yes
TECHNICAL DATA
Dimensions (L x W x H): Reactor module: 360 x 165 x 140 mm
Dimensions (L x W x H): Power supply module: 360 x 165 x 140 mm
Dimensions (L x W x H): Touch Screen Terminal: 10.1" (resolution: 1200 x 800)
Surface material: Aluminium with PTFE coating
Weight: Reactor module: 13 kg
Weight: Power supply module: 7 kg
Weight: Touch Screen Terminal: 2 kg
POWER SUPPLY
Power supply input: 240V–50Hz / 110V–60Hz
Power consumption: 1.2 kW
SYSTEM
System info: Microsoft Windows IoT – 4 GB RAM – 128 GB SSD
Display: Color multi-touch screen
Interfaces: USB, RS232, Ethernet, WLAN, Bluetooth
Temperature control mode: P.I.D.
Data logging: Simultaneous for each reaction cell
Export extensions: Excel, CSV, PDF and graphic visualization
