Max. input voltage: AC 600Vrms(sin) , 848.4Vpeak
Input system: Differential input (can measure floating voltage)
Output voltage: AC 0 - 60mV (output/input: 0.1mV/V)
Measuring ranges: 6 - 600V
Accuracy (Frequency range): ±1.0%rdg±0.1mV (50/60Hz)
Input impedance: Approx. 3.4MΩ
Output impedance: Approx. 180Ω
Output connector: MINI DIN 6PIN
Applicable standards: IEC 61010-1 CAT Ⅲ 600V pollution degree 2
IEC 61010-031, IEC 61326 (EMC)
Location for use: Altitude up to 2000m , Indoors
Operating temperature and humidity range: -10 - 50ºC , relative humidity 85% or less (no condensation)
Dimension: 87(L)×26(W)×17(D)mm (excluding protrusions)
Weight: Approx. 135g
Accessories: Instruction manual
Optional Accessories: 7185 (Extension cable)
