Insulation resistance
Measuring range (Auto range): 100.0MΩ (50V) - 40.00GΩ (1000V)
Accuracy: ±5%rdg (0.050 ~ 0.099MΩ: ±2%rdg±4dgt)
Rated current: 1.0 ~ 1.1mA
Output short circuit current: 1.5mA max
Ω / Continuty
Auto range: 40.00/400.0/4000Ω
Accuracy: ±2.5%rdg ±8dgt
Output voltage on open circuit: 5V (4~6.9V)
Output short circuit current: 200mA max
Voltage
Voltage range: AC 2.0~600V (45~65Hz)
DC -2.0~-600V +2.0~+600V
Accuracy: ±1%rdg ±4dgt
General
Applicable standards:
IEC61010 CATⅢ 600V/CAT IV 300V
IEC61557-1,2,4 IEC61326-1,-2-2 IEC60529 (IP40)
Power source: LR6/R6 (AA) (1.5V)x4
Communication interface: USB , Bluetooth®4.0
Dimensions / Weight: 97(L) x 156(W) x 46(D) mm / 490g approx (including battery)
Included Accessories:
- 7260 (Test leads with remote control switch)
- 7261A (Test leads with alligator clip)
- 8017A (Extension prod long)
- 9173 (Carrying case)
- 9121 (Shoulder strap)
- LR6 (AA) (1.5V)x4
- Instruction manual
Optional Accessories:
- 7243A (L-shaped probe)
- 8016 (Hook type prod)
- 9186A (Carrying case)
- 9187 (Cord case)
- 8212-USB (USB adaptor with "KEW Report (software)" )
