Measuring Range:
DC V: 340.0mV/3.400/34.00/340.0/600V (Input Impedance: 10MΩ)
±1.5%rdg±4dgt
AC V: 3.400/34.00/340.0/600V (Input Impedance: 10MΩ)
±1.5%rdg±5dgt [50 - 400Hz]
DC A: 60.0A ±2%rdg±5dgt
AC A: 60.0A ±2%rdg±5dgt (50/60Hz)
Ω: 340.0Ω/3.400/34.00/340.0kΩ/3.400/34.00MΩ
±1%rdg±3dgt (0 - 340kΩ)
±5%rdg±5dgt (3.4MΩ)
±15%rdg±5dgt (34MΩ)
Continuity buzzer: Buzzer sounds below 30±10Ω
(Continuity buzzer works on 340Ω range only)
Frequency:
(AC A) 3.400/10.00kHz ±0.1%rdg±1dgt
(AC V) 3.400/34.00/300.0kHz ±0.1%rdg±1dgt
(Input sensitivity Current: more than 15A, Voltage: more than 30V)
Conductor size: Ø6mm max.
Applicable standards: IEC 61010-1 CAT III 300V, CAT II 600V
Pollution degree 2
IEC 61010-031, IEC 61010-2-032, IEC 61326-1, EN 50581(RoHS)
Power source: R03 (AAA)(1.5V) × 2
* Continuous measuring time: approx. 45 hours
(Auto power save: approx. 10 minutes)
Dimensions: 128(L) × 87(W) × 24(D)mm
Weight: 210g approx. (including batteries)
Included Accessories: R03 (AAA) × 2, Instruction Manual
Optional Accessories: 9107 (Carrying case [Soft])
