KYOCERA AVX WBP3015W08-H100D3B0A Passive Antenna WX-Family WiFi 6E & 7 PCB 100mm Cable MH

Gain: 3 dBi, 6 dBi

Style: PCB+Cable

Width: 15.5 mm

Height: 0.8 mm

Length: 30 mm

Diameter: 1.13 mm

Bandwidth: 85 MHz, 1.975 GHz

Impedance: 50 Ohms

Cable Type: MH4F

Technology: Wi-Fi / Wi-Fi 6E / Bluetooth / WLAN / BLE / ZIGBEE

Application: Access Points, Routers, Gateways, Wi-Fi enabled TV and Monitor

Cable Length: 100 mm

Polarization: Linear

Power Rating: 2 W

Mounting Style: Adhesive Mount

Electrical Type: Embedded

Frequency Range: 2.4 GHz to 2.48 GHz, 5.15 GHz to 7.125 GHz

Number of Bands: 2 Band

Center Frequency: 2.44 GHz, 6.1 GHz

Mechanical Style: PCB Trace

Maximum Frequency: 7.125 GHz

Minimum Frequency: 2.4 GHz

Termination Style: Connector

Antenna Connector Type: MH4F

Protocol - WiFi - 802.11: 802.11, WiFi, WiFi 6E, WLAN

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE

Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
