KYOCERA AVX 9000154 Passive Antenna Cellular/LPWA PCB (m irror version)

Gain: 0.7 dBi

VSWR: 2.5:1, 2.7:1

Style: Ceramic

Width: 9 mm

Height: 3.2 mm

Length: 35 mm

Impedance: 50 Ohms

Application: Medical Applications, Home Automation, Smart Metering, MWM, Firstnet, Automotive, Healthcare, POS, Tracking

For Use With: Broadband LTE (OCTA-BAND), Cellular LPWA, Firstnet, LTE CAT-M, LoRa, NM-IoT, RPMA< SigFox

Polarization: Linear

Power Rating: 2 W

Mounting Style: PCB Mount

Electrical Type: Embedded

Number of Bands: 2 Band

Center Frequency: 850 MHz, 900 MHz, 1.8 GHz, 1.9 GHz, 2.1 GHz

Mechanical Style: Chip

Ground Plane Size: 50 mm x 110 mm

Maximum Frequency: 2.17 GHz

Minimum Frequency: 824 MHz

Termination Style: SMD/SMT

Protocol - WiFi - 802.11: LoRa, SigFox, LPWA, RPMA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), Cat-M
