KYOCERA AVX 1004796 Passive Antenna Broadband 5G/LTE/LPW A 433MHz or 450MHz o

Gain: 1.6 dBi, 3.1 dBi, 1.7 dBi

VSWR: 2.5:1, 3.0:1

Style: Ceramic

Width: 9 mm

Height: 3.2 mm

Length: 36 mm

Impedance: 50 Ohms

Application: Medical Applications, Weareables, Smart Metering, M2M, Firstnet, Automotive, Healthcare, POS, Tracking

Polarization: Linear

Power Rating: 2 W

Mounting Style: PCB Mount

Electrical Type: Embedded

Number of Bands: 4 Band

Center Frequency: 649 MHz, 1.61 GHz, 1.955 GHz, 2.6 GHz

Mechanical Style: Chip

Maximum Frequency: 2.7 GHz

Minimum Frequency: 600 MHz

Termination Style: SMD/SMT

Protocol - WiFi - 802.11: WiFi, WLAN, LPWA, RPMA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), Cat-M
