Gain: 3.6 dBi, 5.1 dBi
VSWR: 2.0:1
Style: Metal
Width: 17.95 mm
Height: 10.55 mm
Length: 16.1 mm
Impedance: 50 Ohms
Technology: Carbon Comp
Application: Embedded Design, Cellular, Headsets, Tablets, Gateway, Access Point, Handheld, Telematics, Tracking, Healthcare, M2M, Smart Grid, OBD-II
Unit Weight: 2 g
Polarization: Linear
Power Rating: 500 mW
Mounting Style: PCB Mount
Electrical Type: Embedded
Number of Bands: 3 Band
Center Frequency: 2.4425 GHz, 5.4875 GHz, 5.8875 GHz
Mechanical Style: Stamped
Maximum Frequency: 5.925 GHz
Minimum Frequency: 2.4 GHz
Termination Style: SMD/SMT
Protocol - WiFi - 802.11: WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
