Gain: 4 dBi, 4.2 dBi
VSWR: 2:1
Style: Metal
Width: 11.3 mm
Height: 5.1 mm
Length: 45 mm
Impedance: 50 Ohms
Technology: WLAN
Application: Embedded Design, Cellular, Headsets, Tablets, Gateway, Access Point, Handheld, Telematics, Tracking, Healthcare, M2M, Smart Grid, OBD-II
Unit Weight: 8.447 g
Polarization: Linear
Power Rating: 500 mW
Mounting Style: PCB Mount
Electrical Type: Embedded
Number of Bands: 4 Band
Center Frequency: 2.4425 GHz, 5.487 GHz
Mechanical Style: Stamped
Maximum Frequency: 5.9 GHz
Minimum Frequency: 2.39 GHz
Termination Style: SMD/SMT
Antenna Connector Type: U.FL
Protocol - WiFi - 802.11: 802.11 a/b/g/n/c, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
