Measuring angle: 1°
Optical system: SLR viewing system, f = 85 mm F2.8
Angle of view: 9° (with diopter adjustment)
Relative spectral responsivity: Closely matches CIE 1931 color matching function (x (λ), y (λ), z (λ))
Minimum measuring area(diameter): 14.4 mm (1.3 mm when close-up lens is used)
Minimum measuring distance (From the measuring distance reference plane): 1.012 mm. (213 mm when close-up lens is used)
Color notations.: (Absolute value) Lv, x, y (Y, x, y), Lv, u', v', Lv, Tcp, duv, XYZ, Lv. λd, Pe
Measurement mode:
(Luminance) Instantaneous value, maximum/minimum value, luminance difference (Δ)/luminance ratio (%)
(Chromaticity) Instantaneous value, chromaticity difference(Δ)
Measurement time: Auto: 0.7 to 4.3 seconds Manual: 0.7 to 7.1 seconds
Luminance unit: cd/m² or fL
Luminance range: 0.01 to 999,900 cd/m²
Accuracy: (Luminance) ±2% ± 1 digit (Chromaticity) ±0.004 (5 cd/m² or more)
Repeatability: (Luminance) 0.2% + 1 digit (Chromaticity)
0.001 ( 10cd/(m^2) or more)(Chromaticity)
0.002 ( 5cd/(m^2) or more
Calibration standard: Konica Minolta standard/user-specified standard switchable
User calibration channels: 10 channels
Data memory: 1,000 data
Interface: USB2.0
Power: AA-size batteries (x 2 ) USB bus power, or optional AC adapter
Current consumption: When viewfinder display is lit: 70 mA average
Operation temperature/humidity range: 0 to 40°C, relative humidity of 85% or less (at 35 deg * C )
Storage temperature/ humidity range: 0 to 45 deg * C relative humidity of 85% or less (at 35 deg * C )
Size: 71 * 214 * 154 mm
Weight: 850 g (without batteries)
Standard accessories
Lens Cap
Eyepiece ND Filter
Eyepiece Cap
AA-size batteries (x2)
Hard Case CS-A12
Wrist Strap CS-A13
USB Cable T-A15
Data Management Software CS-S20
Optional accessories
Close-Up Lens No. 153/135/122/110
CCD Camera Adapter CS-A14
Illuminance Adapter CS-A15
White Calibration Plate (for 45-0) CS-A20
AC Adapter AC-A305J/L/M
