Illuminating/viewing system: Wide-area illumination/0° viewing angle (specular component included)
Detector: Silicon photocells (6)
Display range: Y 0.01% to 160.00% (reflectance)
Light source: Pulsed xenon lamp
Measurement time: 1 sec.
Minimum measurement interval: 3 sec.
Battery performance: Approx. 800 measurements (when using batteries under Konica Minolta’s testing conditions)
Measurement/illumination area: ø 50 mm / ø 53 mm
Repeatability: Within ΔEab 0.07 standard deviation (when the white calibration plate is measured 30 times at intervals of 10 seconds)
Inter-instrument agreement: ΔEab Within 0.8 (Average of 12 BCRA Series II colors)
Observer: 2° (Closely matches CIE 1931 Standard Observer x̄2, ȳ2, z̄2)
Illuminant: C, D65
Display: Chroma values, color difference values, PASS/WARN/FAIL display
Tolerance judgement: Color difference tolerance (box tolerance and elliptical tolerance)
Color space/colorimetric data: XYZ, Y x y, Lab*, Hunter Lab, LCh, Munsell (only illuminant C), CMC (l:c), CIE1994, Lab99, LCh99, CIE2000, CIE WI-Tw (only illuminant D65), WI ASTM E313 (only illuminant C), YI ASTM D1925 (only illuminant C), YI ASTM E313 (only illuminant C), User index (up to six can be registered from computer)
Languages: Operating keys/English; LCD: English (default), German, French, Italian, Spanish, Japanese
Storable data sets: 1000 (measuring head and data processor save different data)
Color difference target colors: 100
Calibration channels: 20 channels (ch00: white calibration, ch01 to ch19: user calibration)
Display: Dot-matrix LCD with back light (15 chars x 9 lines + 1 line for icon display)
Interface: RS232C compliant (for data processor/PC); Baud rate: 4800, 9600, 19200 (bps) set at 9600 bps when shipped from factory
Power source: 4 AA size alkaline or Ni-MH batteries; AC adapter AC120V 50-60Hz (for N. America and Japan); AC230V 50-60Hz (for worldwide except N. America)
Size: 410: 102 (W) x 244 (H) x 63 (D) mm
Weight: 410: Approx 570g (including 4 AAA size batteries and not including RS-232C cable)
Operating temperature/humidity range: 0 to 40°C, relative humidity 85% or less (at 35°C with no condensation); *North America: 5 to 40°C, relative humidity 80% or less (at 31°C with no condensation)
Storage temperature/humidity range: -20 to 40°C, relative humidity 85% or less (at 35°C with no condensation)
Other: LCD back light ON/OFF function (when ON, back light stays ON for 30 seconds after last key or measurement operation)
