AC large voltage output
Range: (Phase A) 30V, 100V, 300V, 660V, 1000V
Phase B, C: 30V, 100V, 300V, 660V
Stability: 0.01%/1min
Distortion: ≤0.1% (Non-capacitive load)
Output maximum load: 25VA each phase (resistive load)
Accuracy: 0.1%RG
AC small voltage output
Range: phase A: 75mV, 300mV, 750mV, 3V, 7.5V
Output maximum load: ≥ 25mA
Accuracy: 0.1%RG
AC current output
Range: phase A: 500uA, 2mA, 10mA, 50mA, 0.2A, 0.5A, 2A, 5A, 10A, 30A\
Phase B, C: 0.2A, 0.5A, 2A, 5A, 10A, 30A
Output maximum load: 25VA each phase (resistive load)
Power output
Power output stability: 0.02%/2min
Active, reactive power measurement accuracy: 0.1%RG
Phase angle output
Output adjustment range: 0°~360°
Output adjustment resolution: 10°, 1°, 0.1°, or 0.01°
Resolution: 0.01°
Accuracy: 0.05°
Power factor output
Adjustment range: -1 ~ 0 ~ +1
Measurement resolution: 0.0001
Accuracy: 0.0005
Frequency output
Adjustment range: 40Hz ~70Hz
Output adjustment resolution: 1Hz, 0.1Hz, 0.01Hz, 0.001Hz for option
Resolution: 0.001Hz
Accuracy: 0.001 Hz
DC voltage output
Range (4 lines): 100mV, 300 mV, 1V, 5V, 20V, 100V, 300V, 1000V
Ripple amplitude: ≤1%RG (Non-capacitive load)
Output load: 20V and above ranges: ≥10mA; 5V and below ranges: ≥25mA
Accuracy: 0.1%RG
DC current output
Range: 1mA, 3mA, 10mA, 30mA, 100mA, 300mA, 1A, 5A, 10A, 15A, 25A
Accuracy: 10mA and above ranges:0.1%RG
1mA, 3mA range: 0.1%RG
General parameters
Power supply: 90~265VAC/DC
Frequency: 50Hz~60Hz
Consumption: 50VA~1000VA
Environment condition: 20℃~30℃，relative humidity≤85%
Storage environment: -20℃~50℃
Size: 600mm (L) × 440mm (W) × 176mm (H)
Weight: 28Kg
