Kobiconn 164-9008-E Receptacle Housing IDC SOCKET 16 PIN W/STRAIN RELIEF
Pitch: 2.54 mm (0.1 in)
Wire Gauge: 28 AWG
Application: Board-to-Board
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 2.700 g
Contact Gender: Socket (Female)
Current Rating: 1 A
Housing Gender: Female
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Phosphor Bronze / Brass
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: IDC
Number of Positions: 16 Position
Insulation Resistance: 3 Ohms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
