OMEGA SSRDIN660AC55A Single-Phase SSR Vdc & Vac Input/ Vac Output. DIN Rail/Panel Mount
생산업체: OMEGA Model: SSRDIN660AC55A - 연락처
Weight: 600 g
Frequency: 40 to 63 Hz
Power Cycle: Turn-On Time: None; Turn-Off Time: None
Current Output: 55 A
Voltage Output: 48 to 660
Dropout Voltage: 10 Vac
Wire Gauge Note: Input Strandard Wire Gauge: None; Input Solid Wire Gauge: None; Output Stranded Wire Gauge: None; Output Solid Wire Gauge: None
Housing Material: UL 940VD (self-extinguishing)
Input Resistance: None
Number of Phases: 1
Signal fail-safe: None
Thermal Sensitivity: None
Input Control Signal: 90 to 140 Vac
Isolated Analog Voltage: 4000 Vrms
Storage Temperature, Max: 100 °C
Storage Temperature, Min: -40 °C
Input-to-Output Capacitance: 8 pF
Input/Output-to-Ground Isolation: 4000 Vrms
