Fairchild KSC5502DTM BJTs - Bipolar Transistors NPN Triple Diffused Planar Silicon
생산업체: Fairchild Model: KSC5502DTM - 연락처
Width: 6.1 mm
Height: 2.3 mm
Length: 6.6 mm
Technology: Si
Unit Weight: 260.370 mg
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Polarity: NPN
Pd - Power Dissipation: 87.83 W
Gain Bandwidth Product fT: 11 MHz
Emitter- Base Voltage VEBO: 12 V
Collector- Base Voltage VCBO: 1.2 kV
Continuous Collector Current: 2 A
Maximum DC Collector Current: 2 A
Maximum Operating Temperature: + 150 C
DC Collector/Base Gain hfe Min: 14
Collector- Emitter Voltage VCEO Max: 600 V
Collector-Emitter Saturation Voltage: 400 mV
