AC Voltage output
Range: 12×0...450 V
Power: >300VA/Phase
Accuracy: <±0.05%
Resolution: 1mV
AC Current Output
Range: 12×0...100 A
Power: >750VA/ Phase
Accuracy: <±0.05%
Resolution: 1mA
DC Voltage output
Range: 12×0...450 V
Power: >300VA/ Phase
Accuracy: <±0.2%
Resolution: 1mV
DC Current output
Range: 6×0...50 A
Power: >500 VA/ Phase
Accuracy: <±0.2%
Resolution: 1mA
Others
Frequency:
+ Range: 5...1000 Hz
+ Accuracy: <0.001 Hz at 0...65 Hz
<0.01 Hz at 65...450 Hz
<0.02 Hz at 450...1200 Hz
+ Resolution: 0.001 Hz
Phase
+ Range: -360°...360°
+ Accuracy: <0.2°
+ Resolution: 0.1°
Timing
+ Range: 0.1 ms ... 1.5×105 s
+ Accuracy: <1 ms
Harmonic
Harmonic Times: 2...20 Times
Power supply
AC Voltage: 220V±20%
Range: 85V...264V AC
Power: 5000 VA
Frequency: 47 Hz...65 Hz
Operation Conditions
Temperature: -20℃…70℃
Humidity: ≤95%,
Others
Weight: <55 kg
Dimension: 358mm×149mm×297mm
Communication Port: 1×RJ45
