1. AC Withstanding Voltage (AC Hipot)
Output range: 0.05 kV ~ 5.00 kV; 1V; ±(1.2 % of setting + 20 V) (at no load)
Max. rated load: 500 VA(5 kV / 100 mA)
Max. rated current: 100 mA (when the output voltage is 0.2 kV or higher)
Transformer rating: 500 VA
Output voltage waveform: Sine
- Measurement: V, A
- Other function: Judgment, Timer
2. DC Withstanding Voltage (DC Hipot)
Output voltage range: 0.050 kV to 7.200 kV
Resolution: 1 V
Setting accuracy: ±(1.2 % of setting + 20 V)
Max. rated load: 100 W (5 kV/20 mA, 7.2 kV/13.9 mA)
Max. rated current: 20 mA
3. Insulation resistance test section
- Negative polarity:
Output voltage range: -25 V to -1000 V; 1 V; ±(1.2 % of setting + 2 V)
Max. rated load: 1 W (-1000 V/1 mA)
Max. rated current: 1 mA
- Positive polarity:
Output voltage range: +50 V to +7200 V; 1V; ±(1.2 % of setting + 20 V)
Max. rated load: 7.2 W(7200 V/1 mA)
- Measurement: V, R
- Other function: Judgment, Timer
4. General
Interface: REMOTE, SIGNAL I/O, SCANNER, USB, Remote control
Power supply
Nominal voltage range(allowable voltage range): 100 Vac to 120 V, 200 V to 240 V (90 Vac to 132 V, 170 V to 250 V)
Power consumption:
No load(READY state) 100 VA or less
Rated load 800 VA max.
Allowable frequency range: 47 Hz ~ 63 Hz
Weight: Approx 18 kg (39.7 lb.)
Accessories:
Power cord : 1pc.
High test lead (TL31-TOS) : 1set
SIGNAL I/O plug (1 set)
High-voltage warning sticker (1 pc.)
Setup Guide (1 copy)
CD-ROM (1 disc)
Safety Information (1 copy)
Heavy object warning label
